罩式洗碗机H60

特点及优势：

内置喷淋泵，克服水压波动，带来稳定的喷淋效果；

独特的四面全封闭罩式门，当门罩被提起时，蒸汽和热量上升并被保留在门罩内，而不是释放到洗碗间内；

独特设计的喷嘴，使喷水效果更加稳定均匀，覆盖范围广；

两个可选洗涤周期，可根据餐具情况选择洗涤周期；

全自动注水，水位自动控制，防止干烧

机械式按钮设计，操作简单；

高亮LED温度显示，一目了然；

可选配双层上罩，节能降噪，使操作环境更加舒适；

可选配热回收模块，进一步降低机器能耗；

主要适用场所

中、小型饭店、咖啡厅、连锁餐厅、食堂

参数

项目/型号	H60	H60S
电源要求	380V/50Hz/3P	380V/50Hz/3P
进水温度(℃)	10-60	10-60
水槽加热功率(千瓦)	3	3
漂洗加热功率(千瓦)	7×2	7
清洗水泵功率(千瓦	0.735	0.735
漂洗水泵功率(千瓦)	0.23	0.23
总功率(千瓦)	18	11
总电流(安)	28	17
电源线截面(mm²)	6	4
空气开关额定电流（安）	40	25
外形尺寸(毫米)	713×835×1508	836×835×1508
加热方式	电加热
机器入口宽度 (毫米)	508
最大洗涤高度(毫米)	420
最大洗涤量（筐/小时）	60
耗水量(升/筐)	2.5
水箱容积(升)	32
升温器容积(升)	14
洗涤温度(℃)	60~65
漂洗温度(℃)	82~90
洗涤周期(秒)	60/90
进水管径(英寸)	3/4
排水管径(英寸)	1.25
进水压力(千克/平方厘米)	0.3-5
进水硬度(克/升)	0.034-0.103

Hood Type Dishwasher H60

Characteristics and Advantages

Built-in rinse pump could overcome the fluctuation of water pressure and bring steady rinse effect.

Unique design of cover closed doors could let steam and heat rise and kept inside the door hood instead of being released into dishwashing room when the door hood is lifted.

Uniquely designed nozzle makes the water spraying more stable and uniform, which covers a wide range.

Two optional washing cycles could be selected according to the situation of tableware.

Automatic water injection could automatically control water level and prevent dry heating.

Mechanical button design makes the operation simple.

Highlighted LED temperature display makes it clear at a glance.

Optional double skin hood saves energy and reduce noise to make more comfortable operating environment.

Optional heat recovery module further reduces the energy consumption of the machine.

Ideal For

Medium and small hotels, coffee shops, chain –restaurants and dining halls.

Parameter

Item/Model	H60	H60S
Power Requirements	380V/50Hz/3P	380V/50Hz/3P
Incoming water temperature(℃)	10-60	10-60
Tank heater(Kw)	3	3
Booster heater(Kw)	7×2	7
Wash Pump (Kw)	0.735	0.735
Rinse Pump (Kw)	0.23	0.23
Total connected load(Kw)	18	11
Total Amps required(A)	28	17
Cross section of cable (mm²)	6	4
Rated current of air circuit breaker（A）	40	25
Appearance dimension(mm)	713×835×1508	836×835×1508
Heating	Electricity
Passing width (mm)	508
Max clear entry height(mm)	420
Max capacity（rack/hour）	60
Water consumption(liter/rack)	2.5
Wash tank capacity(liter)	32
Booster capacity(liter)	14
Wash temperature(℃)	60~65
Rinse temperature(℃)	82~90
Wash cycle(s)	60/90
Diameter of the water inlet hose(in)	3/4
Diameter of drainpipe(in)	1.25
Incoming water pressure(Kg/cm²)	0.3-5
Incoming water hardness(g/l)	0.034-0.103
